How to Measure a Garage Door

How to Measure a Garage Door

A garage door is a large door that is typically used to provide access to a garage, which is a building or a part of a building that is designed to store vehicles or other items. It is designed to be opened and closed manually or automatically using a motorized system. Garage doors are typically made of wood, steel, or aluminum, and they can be operated manually or electronically.

Measuring a garage door is important because it allows you to determine the correct size of door that you need for your garage. If you order a door that is too small, it may not fit properly and could leave gaps that allow air, moisture, or even pests to enter your garage. On the other hand, if you order a door that is too large, it may not be able to fully open or close due to space limitations, and could also be more expensive than necessary.

In this guide, we will show you easy and in-depth steps to measure a Garage door accurately.

5 Easy Steps to Measure Your Garage Door

Measuring a garage door is an important step in the process of installing a new door. Here are the steps you can follow to measure your garage door:

  • Step 1: Measuring The Width Of The Garage Door

Stand inside the garage facing the opening, and measure the distance from the left side of the opening to the right side. Take your measurement at the widest point of the opening. Round your measurement up to the nearest inch. For example, if your measurement is 9 feet and 8 inches, round up to 10 feet.

  • Step 2: Measuring The Height Of The Garage Door

Stand inside the garage and measure the distance from the floor to the top of the opening. Take your measurement at the highest point of the opening, which is usually the center. Round your measurement up to the nearest inch. For example, if your measurement is 7 feet and 11 inches, round up to 8 feet.

  • Step 3: Measuring The Headroom

Measure the distance from the top of the opening to the ceiling or any obstructions that might be in the way. This measurement is known as the headroom. Ensure that there is enough headroom for your garage door and any garage door opener that you plan to install. Standard garage doors require at least 12 inches of headroom, but some may require more.

  • Step 4: Measuring The Backroom

Measure the distance from the back of the opening to the back wall of the garage. This measurement is known as the backroom. Ensure that there is enough backroom for your garage door and any garage door opener that you plan to install. Standard garage doors require at least 4 inches of backroom, but some may require more.

  • Step 5: Measuring The Side Room

Measure the distance from the side of the opening to the nearest obstacle, such as a wall or pillar. This measurement is known as the side room. Ensure that there is enough side room for your garage door and any garage door opener that you plan to install. Standard garage doors require at least 3.75 inches of side room, but some doors and openers may require more. Repeat the measurement on the other side by measuring the distance from the other side of the opening to the nearest obstacle, and make sure it is the same as the first measurement.

By taking accurate measurements of the width, height, headroom, sideroom, and backroom of your garage door opening, you can ensure that you order the correct size and type of garage door for your needs.

Garage Door Measurement Tips

Here are some tips to help you accurately measure your garage door:

  • Use a Tape Measure

Use a reliable tape measure to ensure accurate measurements. Avoid using a ruler or yardstick, as they are not long enough to measure the full height or width of the garage door opening.

  • Measure Twice

Always double-check your measurements to ensure accuracy. A small error in measurement can result in a door that doesn't fit properly, leading to problems with opening, closing, and even safety issues.

  • Measure from Multiple Points

When measuring the height and width of the garage door opening, take measurements from multiple points to ensure consistency. This will help you identify any variations or irregularities in the opening.

  • Consider the Space Required for Hardware

When measuring for your garage door, consider the space required for hardware such as tracks, springs, and the opener. Make sure there is enough space for all components to operate smoothly.

By following these tips, you can ensure that you get accurate measurements for your garage door, which will help you select the right size and type of door for your needs.

What Are The Standard Garage Door Sizes?

In the UK, the most common standard garage door sizes are:

Single garage door - 7 feet wide by 6 feet 6 inches high (2134mm x 1981mm)

Double garage door - 14 feet wide by 6 feet 6 inches high (4267mm x 1981mm)

However, these are just the most common standard sizes and garage doors can be custom-made to fit a wide range of openings. It's important to accurately measure the height, width, and backroom of your garage door opening to ensure that you choose the right size of door for your needs.

Conclusion

It's important to take accurate measurements and to consider any obstructions or unusual features that may affect the installation of the door. By doing so, you can ensure that your new garage door will fit properly and function correctly. If you are looking to install good quality external doors and internal doors in your home, check out Emerald Door's wide range of door options to choose from.

FAQs on How to Measure a Garage Door

  • Are all garage doors standard size?

No, not all garage doors are standard size. While there are common standard sizes for garage doors, there are also many variations in size and shape depending on the specific needs and dimensions of the garage. Garage doors can be customized to fit different opening sizes and shapes, including wider or taller openings, or openings with unusual shapes.

  • Do garage doors have one or two springs?

Garage doors can have one or two springs, depending on the weight and size of the door. Single-car garage doors typically have one torsion spring, while larger double-car doors may have two torsion springs.

  • Is a garage door the same size as the opening?

No, a garage door is typically slightly smaller than the opening it is installed in. This is because the door needs to be able to move freely and have enough clearance to operate properly without scraping against the sides of the opening. The amount of space required between the door and the opening will depend on the type of garage door being installed.

  • What makes a garage door more expensive?

There are several factors that can contribute to the cost of a garage door, including material, insulation, design & style, brand, installation, and more. When choosing a garage door, it's important to consider your budget and the features and benefits that are most important to you to help find the right door for your needs at a price you can afford.
